- Stall Prevention Functions for stable operation during changes of load or power supply
- Over-Excitation Braking for quick deceleration without external braking resistor
- Detects load and automatically adjusts torque regardless the actual speed conditions
Technical Details
- INPUT POWER SUPPLY
- 200 V
- INPUT POWER PHASES
- 3-phase
- RATED OUTPUT CURRENT (HD)
- 11 A
- RATED OUTPUT CURRENT (ND)
- 12 A
- MAX. APPLICABLE MOTOR OUTPUT (HD)
- 2.2 kW
- MAX. APPLICABLE MOTOR OUTPUT (ND)
- 3 kW
- MOTOR TYPE
- Induction motor
- STANDARDS COMPLIANCE
- cUL, CE, RoHS, UL
- AMBIENT TEMPERATURE (MIN)
- -10 °C
- AMBIENT TEMPERATURE (MAX)
- 40 °C
- AMBIENT TEMPERATURE (MAX) WITH DERATING
- 50 °C
- MAX. HUMIDITY (NON-CONDENSING)
- 95 %
- MAX. ALTITUDE (WITHOUT DERATING)
- 1,000 m
- MAX. ALTITUDE (WITH DERATING)
- 3,000 m
- HEIGHT
- 128 mm
- WIDTH
- 108 mm
- DEPTH
- 137.5 mm
- WEIGHT
- 1.7 kg
- ENCLOSURE
- IP20 (without top cover)
- ENVIRONMENTAL SPECIFICATIONS
- Standard
