| Features | Descriptions |
| Physical Features | |
| Dimensions | 96 mm x 96 mm 87,5 mm |
| Protection Class | NEMA 4X (IP65 at front, IP20 at rear) |
| Installation | Fixed Installation |
| Storage / Operating Temperature | -40 ºC with +85 ºC / 0 ºC with +50 ºC |
| Storage / Operating Humidity | 90 % max. (None condensing) |
| Electrical Features | |
| Supply Voltage and Power | 100-240 Vac (-15%,+10%) 50/60 Hz. 6 VA 24 Vac (-15%,+10%) 50/60 Hz. 6 VA 24 Vdc (-15%,+10%) 6 W |
| Sensor Inputs | 12 Vdc Maximum 50 mA |
| Optional Sensor Inputs | |
| Scale | |
| Accuracy | |
| Output | |
| Relay Output | EM0-900 Relay Output Module (3A @ 250V) |
| SSR Output | |
| Analogue Output | |
| Optional Outputs | EM0-410 SSR Output Module (20mA @ 18V) EM0-420 Dijital (Transistor) Output Module (40mA @ 18V) |
| Control | |
| Control Form | |
| Reading Frequency | |
| Communication Protocols | MODBUS-ASCII or RTU |
| Approvals | UL Recognized Component (File No : E 254103), EAC, CE |
