General | |||
Casing Width (mm) | 17,5 | ||
Connections | Screw terminal | ||
Input | Sensor Type | PT100 | |
Connection Method | 2 wire or 3 wire or 4 wire | ||
Temperature Measuring Range | -150°C +800°C Configurable | ||
Sensor Excitation Current | <0.5mA | ||
Output | Output Signal | 0..5V ,0..20mA, 5..0V,20..0mA , 0..10V,4..20mA , 10..0V, 20..4mA, -5..5V,20..20mA | |
Linear Output Range | |||
Max. Load | ≤ 600 Ω ( Current İnput ), ≥ 10K Ω ( Voltage Output ) | ||
Ripple | — | ||
Supply | Voltage | AC | — |
DC | 11-30V | ||
General | Isolation | 3 way – 1,5 kV RMS | |
Measurement Error | < 0.2% (Full Scale) | ||
Temperature Coefficient | ≤ 0.02%/°C | ||
Response Time | < 150ms | ||
Sensor Failure Indication | The situation of input signal is at least 10 % different than adjusted value | ||
Ambient Conditions | Operating Temperature | -20°C +60°C | |
Storing Temperature | -40°C +75°C | ||
Relative Humidity (No Condensation) | Maks. 95% | ||
General | Protection Class | IP20 | |
Mounting Type | Rail Mounted | ||
EMC-EMI | Radiated Emissions Test, 61000-6-2/AC:2012, 61000-6-4:2007/A1:2011 | Any | |
General | Packing Unit | 1 | |
Dimensional Drawings | — | ||
Weight (g) | 42 |
