| General | |||
| Casing Width (mm) | 17,5 | ||
| Connections | Screw Terminal (for supply and serial interface) | ||
| Working Mode | Server or Client Selectable (bidirectional) | ||
| Configuration | Mini USB Port or Web Interface | ||
| DHCP (Automatic IP Receive) | ✔ | ||
| ARP | ✔ | ||
| Ping Blocking | ✔ | ||
| LED Indicators | ✔ | ||
| Reset Function | ✔ | ||
| ESD Protection | ✔ | ||
| Driver Supported | Windows XP/Vista/7/8/8.1 | ||
| Ethernet Interface | Number of Ports | 1 | |
| Operation Modes | Modbus TCP, Modbus RTU over TCP, Modbus ASCII over TCP | ||
| Ethernet Interface | Number of Remote Connections | Server Mode | 6 |
| Client Mode | 1 | ||
| Ethernet Interface | Connector | RJ45 | |
| Data Transmission Rate | 10/100 Base-TX | ||
| Serial Interface | Number of Ports | 1 | |
| Operation Modes | Modbus RTU, Modbus ASCII | ||
| Serial Standart | RS485 | ||
| Serial Interface | Number of Serial Devices | Server Mode | 64 |
| Client Mode | 1 | ||
| Serial Communication Parameters | Baud Rate | 300 to 115200 bps | |
| Data Bit | 8 | ||
| Stop Bits | 1 or 2 | ||
| Parity | None, Even, Odd | ||
| Supply | Voltage | AC | 18-50V |
| DC | 18-50V | ||
| Consumption | AC | <2.2VA | |
| DC | <1.2W | ||
| Supply | Frequency | 45-65Hz | |
| Galvanic Isolation | Supply – Ethernet Port | 1500VRMS, 2250VDC | |
| Supply – Serial Port | 1500VRMS, 2250VDC | ||
| Serial Port – Ethernet Port | 2500VRMS | ||
| Mechanical Properties | Weight (g) | 58 | |
| Packing Unit | 1 | ||
| Protection Class | IP20 | ||
| Assembly Type | Rail Mount | ||
| Ambient Conditions | Operating Temperature | -10°C +60°C | |
| Storing Temperature | -30°C +80°C | ||
| Relative Humidity (No Condensation) | Maks. 95% | ||
| EMC-EMI | TS EN 55022, TS EN 55024 | ||
| General | Schematics | ||
