Specifications
- Valve Actuation
- Solenoid – Air Pilot
- Pipe / Port Size
- 1/8; 1/4; 6 mm; 8 mm
- Port Type
- G ISO228/1-G BSPP; NPTF; Push-in
- Function
- 4 way – 5/2; 4 way – 5/3; 4 way – 5/3 – Closed Center; 4 way – 5/3 – Open Center; 4 way – 5/3 – Pressure Center; Dual 3 – Way 2 X Normally Closed; Dual 3 – Way 2 X Normally Open
- Flow
- From .05-.1 Cv
- Standards / Regulations
- CSA; IP65; ISO
- Operating Environment
- Indoor; Outdoor; Washdown
- Media
- Air, Inert Gas; Vacuum
Features
- Pressure regulators increase energy efficiency and optimize power consumption
- Meets ISO 15407-2 standard for drop-in replacement
- Modular design for easy configuration
- Speed controls optimize machine cycling
- Individual valves are pressure isolated for easy maintenance
- Modular G3 fieldbus electronics and I/O compatibility enable easy networking
- Plug together circuit boards eliminate internal wiring
- Interchangeable push-in fittings accommodate various tube sizes
- Port sizes include 1/8 threaded, 1/4 push in, 6 mm, and 8 mm
