Specifications
- Local display
-
• Graphical display with optional backlight setting
• Four-button capacitive touch controls
• Supports English, German, French, Spanish, Portuguese, Russian, Chinese, and Japanese languages.
- Power
-
• 2-wire loop-powered transmitter
• Minimum 17.75 V lift off voltage.
- Input/output signals
-
• Up to 2 output channels
• Channel A is loop-powered 4-20mA/HART
• Chanel B is externally-powered configurable for 4-20mA, frequency output or discrete output (Licensable Option)
- WirelessHART
- • WirelessHART available with THUM adapter
- Mounting options
-
• Field-mount
• Integrally mounted to a Micro Motion ELITE (CMFS), CMF200-CMF350, F-series, H-series, R-series, and T-series sensors
• Remotely mounted 9-wire with mounting bracket
- Application types
-
• Smart Meter Verification
• Concentration measurement
• API Referral
- Hazardous approvals
-
• Class I, Div. 1
• Class I, Div. 2
• Zone 1
• Zone 2
• Intrinsically Safe
• Explosion Proof
Features
- Available with a wide range of Coriolis mass flow sensors with up to +/-0.10% mass flow accuracy and +/0.0005 g/cc density accuracy for liquids and slurries or +/-0.25% mass flow accuracy for gases.
- The integrated real-time clock time stamps process data, alerts, Smart Meter Verification reports and audit logs. Data Historian on board offers a complete audit trail to determine process issues.
- Graphic display that supports 8 languages and can be rotated using the integrated software rotation without removing the front cover, thereby minimizing downtime due to hot work permit restrictions.
- Replace existing 2-wire flow devices with minimal effort and without incurring additional power or cabling costs.
- Easily expand your plant where power is not centrally located
- Smart Meter Verification provides a quick, complete assessment of a Coriolis meter, determining whether the meter has been affected by erosion, corrosion, or other influences affecting meter calibration. A basic version of Smart Meter Verification is included as standard.
- Certified for SIL2 single use and SIL3 multiple use safety applications per IEC 61508
- Accurate, repeatable, direct mass measurement improves process control while reducing number of measurement devices required.
- Wireless THUM™ option maximizes installation and operation flexibility.
