Specifications
- Housing
- Polyurethane-paintedcast aluminum or stainless steel; NEMA 4X (IP66)
- Weight
- Painted aluminum, 4-wire remote:
- with display: 8 lb (4 kg)
- without display: 7 lb (3kg)
Painted aluminum, 9-wire remote:
- with display: 14 lb (6 kg)
- without display: 13 lb (6 kg)
Stainless steel, 4-wire remote:
- with display: 21 lb (10 kg)
- without display: 20 lb (9 kg)
View product data sheet for full details.
- Mounting
- Integralor remote mounting options (stainless steel versions are remote mount only)Maybe remotely connected to any 4-wire or 9-wire Micro Motion sensorView product data sheet for full details.
- Available Outputs
- 1700: mA w/ Bell 202 HART FO/DO RS485 HART and Modbus
2700:
Analog: mA w/ Bell 202 HART FO/DO RS485 HART and Modbus
Configurable I/O: mA w/Bell 202 HART configurable to mA, FO, or DO (default mA)configurable to FO, DO, orDI (default FO)
View product data sheet for full details.
Features
- Maximize flexibility with integral or remote mounting
- Receive diagnostics for performance under entrained gas and batching from empty applications with MVD digital processing
- Lower wiring costs and install easily and quickly
- Eliminate the need for additional instruments with concentration and net flow measurement
- Rely on custody-transfer approval and certification for SIL2 and SIL3
- Gain real-time and in-process measurement integrity assurance with Smart Meter Verification
- Gain access to additional diagnostics and process information without added wiring costs with WirelessHART™
- Simplify flow-meter access with rugged Class I, Division 1 / Zone 1 housing with an optional local operator interface
