Specifications
- Body Size and End Connection Styles
- NPS 3/4 x 3/4, 3/4 x 1, 1 x 1, NPT All sizes available in Globe or Angle Body
- Allowable Inlet Pressure
- Emergency: 150 psig / 10,3 bar
Maximum Operating Pressure: 125 psig / 8,6 bar
- Allowable Outlet Pressure
- Emergency (Casing): 25 psig / 1,7 bar
Maximum Operating Pressure to Avoid Internal Parts Damage: 3 psi / 0,21 bar differential above outlet pressure setting
- Outlet Pressure Ranges
- 4-inches w.c. to 2.2 psig / 10 mbar to 0,15 bar in 7 ranges
- Pressure Registration
- Internal
- Temperature Capabilities
- -20 to 160°F / -29 to 71°C
- Approximate Weight
- 4 Pounds / 2 kg
Features
- Angle Bodies?
- Globe Bodies
- High Capacity
- Compact Design
- High Capacity Internal Relief
- Meets or Exceeds ANSI B109.4 / CGA 6.18 Requirements
- Fixed Factor / PFM Accuracy
