Specifications
- Body Sizes and End Connection Styles
- NPS 2 / DN 50 body with NPT, CL125 FF, CL150 RF, CL250 RF, CL300 RF end connections
- Maximum Inlet Pressure
- 160 psig / 11.0 bar: Type 61LD pilot
400 psig / 27.6 bar: Types 61L, 61LE, and 61H pilots
1000 psig / 69.0 bar: Type 61HP pilot with Type 1301F and Type H110 (1/2 / 13 mm orifice only)
- Maximum Outlet Pressures
- 100 psig / 6.9 bar
- Outlet Pressure Ranges
- 2-inches w.c. to 100 psig / 5 mbar to 6.9 bar in nine ranges
- Pressure Registration
- Internal
- Temperature Capabilities
- With Nitrile (NBR) / Neoprene (CR) / Nylon (PA): -20 to 180°F / -29 to 82°C
With Fluorocarbon (FKM): 0 to 300°F / -18 to 149°C
- Approximate Weight
- 115 Pounds / 52 kg
Features
- High Accuracy
- No Atmospheric Bleed
- Can Handle High Inlet Pressures
- Easily Modified for Special Service
- Tight Shutoff
- High-Capacity Pressure Control
- Excellent Low Flow Control
- Three Pilots to Choose From
