Specifications
- Area Classification
- Group II Category 2 Gas and Dust
- Certifications
- ATEX, PED, CUTR
- Data Interface
- Wired
- Diagnostics
- No
- Max Outlet Pressure
- 35 psi / 50 psi
- Mounting Type
- Process Vessel Mounted
- Operating Temperature
- Standard Temperature
- Position Control
- On/Off, Monitoring
- Process Control
- Level
- Supply Media
- Air, Natural Gas
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- Two-stage proportional relay with integral action provides more dependable liquid level control.
- O-ring friction and process pressure sensitivity are minimal. Performance stays constant with process pressure changes and controller remains vibration-resistant.
- The displacer may be adjusted in the field for vertical or horizontal operation without additional parts.
- The controller can be adjusted in the field for direct or reverse action without additional parts.
- Sensor assembly is designed and specified for ASME B16.34 CL1500 service when using a Polyvinylchloride (PVC) displacer.
- The ability to pipe away exhaust permits using natural gas as the operating medium.
- Both the controller and the sensor can be easily disassembled to inspect the process seals and for maintenance.
