Specifications
- Certifications
- Fugitive Emission, CRN, CE, PED
- End Connection
- Flanged
- Application
- Powder Filling
- Body Design
- Side Entry, Long Pattern
- Material
- 316 Stainless Steel, Carbon Steel
- Operating Temperature
- Up to 350 F (180 C)
- Pressure Class
- ASME
- Process Connection Type
- CL600RF, Flanged, CL300RF, 600RF, 300RF, 150RF, CL150RF
- Seat/Seal Type
- Ball, Metal-to-Metal
- Shutoff Class
- Class VI (FCI 70-2), Class V (FCI 70-2)
- Standards
- API 608, ASME B16.34
- Valve Size
- NPS 3 / DN 80, NPS 4 / DN 100, NPS 6 / DN 150, NPS 8 / DN 200, NPS 2 / DN 50, NPS 12 / DN 300, NPS 10 / DN 250
- Valve Size Standard
- DN, NPS
- Valve Type
- Trunnion Ball Valve, Ball Valve
- Stem
- Live loaded, Adjustable packing
Features
- For use in on-off powder service such as polyethylene, polypropylene and hydrocarbon vapor mixture etc.
- Superior seating: ANSI/FCI 70-2
- Spring loaded seat maintains close contact with ball assuring tight sealing even at low pressure. This results in stable opening and closing torques at high differential pressures over a wide range of temperatures.
- Scraper design for metal seat mechanically minimizes residual powder between surfaces of ball and seat to maintain seal ability during operation and to maintain smooth open-close action.
- Powder proof devices around seat areas. The spring area is shielded from contaminants by means of innovative ring to provide a constant and stable seat loading to ensure smooth operation.
- The valve stem is made of low alloy steel to maintain high strength. Electroless nickel plating for corrosion and abrasion resistance.
- A non-lubricated dry PEEK bearing with low friction (for upper stem and lower stem) provides high abrasion resistance.
- Allowable min temp. of the actuator is -45°C.
