Specifications
- Area Classification
- Explosion Proof, Intrinsically Safe, Non-incendive, General Purpose, Flame Proof
- Certifications
- CSA, FM, ATEX, IECEx, CUTR, Regional
- Communication Protocol
- 4-20mA Analog
- Data Interface
- Wired
- Diagnostics
- No
- Input Signal
- Electric
- Max Outlet Pressure
- 33 psig
- Mounting Type
- Remote Mount, Actuator Mount
- Operating Temperature
- Standard Temperature
- Position Control
- Modulating Control
- Power Source
- Local
- Supply Media
- Air, Natural Gas
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- Approved for use with natural gas as the pneumatic supply.
- Low pneumatic supply consumption, which lowers operating costs.
- Has been tested in accordance with ANSI/ISA Standard 12.27.01
- The integral output relay volume of the transducer is adequate to drive valve/actuator combinations without requiring a positioner or volume booster.
- Selectable user field-configurable two-way split range, using either half of the standard input signal.
- Separate housing compartments isolate the electronics from the pneumatic process..
- Free-flow pilot stage design and large internal air passages provide excellent tolerance to dirty pneumatic supply by reducing the effects of contaminant build-up and erosion.
