Specifications
- Certifications
- PED, CUTR, ATEX, CRN
- Critical Service
- General Service
- Flow Characteristics
- Equal Percentage
- Material
- Carbon Steel
- Operating Temperature
- Standard Temperature
- Pressure Class
- ASME CL900 (NPT), ASME CL600 (RF)
- Process Connection Type
- Threaded, Flanged
- Shutoff Class
- Class IV (FCI 70-2)
- Valve Size
- NPS 1, NPS 2
- Valve Size Standard
- NPS
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- Pneumatic or electric actuation is available.
- Features ENVIRO-SEAL™ packing technology to provide reduced packing maintenance and meet Low E fugitive emission requirements for Leak Detection and Repair (LDAR) programs in compliance with the Code of Federal Regulations (CFR) 40, Part 60, Su
- D3 valves are available with tungsten carbide trim for erosive service. Fisher tungsten carbide trim is designed specifically for severe service applications in the oil and gas industry.
- A selection of end connections, trim materials, and flow capacities allows the D3 to be used in a broad range of applications, including sour service.
- The standard D3 FloPro trim, valve body, and bonnet meet the metallurgical requirements of NACE MR0175/ISO 15156.
