Specifications
- Certifications
- PED, ATEX, CRN
- Critical Service
- General Service
- Flow Characteristics
- Characterization
- Material
- Carbon Steel
- Operating Temperature
- Standard Temperature
- Pressure Class
- ASME CL900
- Process Connection Type
- Threaded
- Shutoff Class
- Class IV (FCI 70-2)
- Valve Size
- NPS 1
- Valve Size Standard
- NPS
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- Includes a pipe plug that allows for the D2T body to be configured as a globe valve or angle valve.
- 1 NPT end connections are available.
- Features a CL900 (2250 psig) pressure rating.
- FloPro field selectable flow rate for 1/4, 3/8, and 1/2 inch port size.
- Solid Alloy 6 erosive service trim.
- Has a full 2250 psig pressure drop capability.
- Valve is NACE service ready.
- ENVIRO-SEAL™ D2T packing system is available.
