Specifications
- Power Source
- Electric
- Product Type
- Electric Actuator
- Actuation
- Electric
- Certifications
- CSA, NEMA
- Control Type
- On/off, Positioning, Throttling
- Valve Type
- Ball, Butterfly, Plug, Choke
- Torque/Thrust
- Quarter-turn torque: 11 Nm (8 ft lbs) to 2,260 Nm (1,667 ft lbs)
Features
- Five models with output torques ranging from 100 in-lbs-in to 20,000 in-lbs-in (11 Nm to 2,260Nm)
- Standard for torques as low as 350 lbs-in through 10,000 lbs-in torques is 100% (none less than 50% in all available motor voltages)
- Compact design in weatherproof and explosion-proof housings
- Modular design readily accommodates controls and accessories such as heaters, motor brakes, positioners, transmitters and control stations
- Permanent lubrication reduces the need for scheduled maintenance
- High strength gearing run in needle bearings for smooth energy transfer and long service life
