Specifications
- Area Classification
- Explosion Proof, Intrinsically Safe, Non-incendive, General Purpose, Flame Proof
- Certifications
- CSA, FM, ATEX, IECEx, CUTR, Regional
- Communication Protocol
- 4-20mA Analog, Discrete Alarms
- Data Interface
- Wired
- Diagnostics
- No
- Input Signal
- Electric
- Mounting Type
- Actuator Mount
- Operating Temperature
- Standard Temperature
- Position Control
- Modulating Control
- Power Source
- Local
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- A precision film-element potentiometer in the standard unit and a precision multi-turn wirewound potentiometer in the long-stroke unit provide exceptional linearity by matching the span of the sense element to the application.
- To eliminate the need for externally mounted mechanical limit switches, instruments with travel limit alarms incorporate comparator circuits that monitor the sense potentiometer voltage output.
- Electronic travel limit alarms have an adjustable deadband up to 10 percent of the maximum span.
- The instrument, even with travel limit alarms, uses little space when mounted, allowing room for additional devices.
- A simple hybrid electronic design combines the best qualities of discrete components and integrated circuits for improved reliability and performance.
- The field wiring compartment is isolated from the electronic compartment. This protects the electronic circuits from any moisture brought into the housing via the field wiring ports.
