Specifications
- Valve Actuation
- Solenoid – Latching
- Body Material
- Brass, Stainless Steel
- Media
- Air, Inert Gas, Light Oil, Steam
- Pipe / Port Size
- 1/4 “; 3/8 “
- Port Type
- NPTF
- Function
- 3 way – 3/2 Universal
- Flow
- From 0.1 Cv to 0.5 Cv, From 0.5 Cv to 1.0 Cv
- Voltage
- 24 AC, 120 AC, 480 AC, 6 DC, 12 DC, 24 DC, 48 DC, 120 DC, 240 DC | 60
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Hazardous, Indoor
- Standards / Regulations
- CSA, Type 3, Type 7, Type 9
Features
- Once tripped, the valves can only be manually reset
- Available for latched-open or latched-closed operation
- Intrinsically safe constructions can be installed in challenging environments
- Brass or stainless-steel bodies are available
