Specifications
- Valve Actuation
- Solenoid
- Body Material
- Brass, Stainless Steel
- Media
- Air, Inert Gas, Natural Gas, Water
- Pipe / Port Size
- 1/2 “; 3/8 “; 3/4 “
- Port Type
- NPTF
- Function
- 2 way – 2/2 Normally Closed, 2 way – 2/2 Normally Open
- Flow
- From 2.0 Cv to 6.0 Cv, From 6.0 Cv to 14.0 Cv
- Voltage
- 24 AC, 110 AC, 120 AC, 220 AC, 230 AC, 480 AC, 6 DC, 12 DC, 24 DC, 120 DC, 240 DC | 50/60
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Indoor, Outdoor
- Standards / Regulations
- CSA, FM, UL
Features
- Ideal for low pressure general service and vacuum applications
- Brass constructions available for fuel gas service in commercial and industrial gas burners
- Gas shutoff model has 2-way normally closed operation
- Gas vent model has 2-way normally open operation
- Most constructions mountable in any position for convenient installation
