Specifications
- Valve Actuation
- Solenoid – Latching
- Body Material
- Brass; Stainless Steel
- Media
- Air, Inert Gas; Light Oil; Steam; Water
- Pipe / Port Size
- 3/4 “; 1 “; 1 1/4 “; 1 1/2 “
- Port Type
- NPTF
- Function
- 2 way – 2/2 Normally Closed; 2 way – 2/2 Normally Open
- Flow
- From 6.0 Cv to 14.0 Cv; Over 14.0 Cv
- Voltage
- 24 AC; 120 AC; 480 AC; 6 DC; 12 DC; 24 DC; 120 DC; 240 DC – 60
- Max Differential / Max Operating Pressure
- 150-500 PSIG
- Operating Environment
- Corrosive; Hazardous; Indoor
- Standards / Regulations
- CSA; Type 3; Type 7; Type 9
Features
- Electrically tripped (trips when energized) or no voltage release (trips when de-energized) constructions
- Available for latched-open or latched-closed operation
- Handles air, inert gas, water, light oil, steam, and corrosive fluids
- Brass or stainless steel constructions meet a wide range of applications
