Specifications
- Valve Actuation
- Solenoid
- Body Material
- Engineered Plastics
- Media
- Aggressive Liquids/Gases
- Function
- 3 way – 3/2 Normally Closed, Closed Center; 3 way – 3/2 Universal
- Flow
- Less than .05 Cv, From .43 to .86 Kv
- Voltage
- 12 DC;24 DC | 50/60
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Corrosive, Indoor
Features
- Compact manifold design saves space and reduces assembly time
- Excellent self-draining capability and easy-to-flush, low-volume internal cavity make the valves ideal in applications where cross-contamination must be minimized
- Removable and rotatable electrical coils allow for easy installation and worry-free maintenance
- Available with inert materials of construction, such as PEEK and FFKM, to handle aggressive chemicals or high-purity media
