Specifications
- Valve Actuation
- Solenoid – Direct Acting
- Body Material
- Engineered Plastics
- Media
- Air, Inert Gas
- Pipe / Port Size
- 1/4 “
- Function
- 3 way – 3/2 Normally Closed, 3 way – 3/2 Normally Open
- Flow
- From .05-.1 Cv
- Voltage
- 24 AC, 110 AC, 120 AC, 440 AC, 6 DC, 12 DC, 24 DC, 48 DC, 120 DC, 240 AC
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Indoor
- Operating Environment
- Corrosive, Hazardous, Outdoor
Features
- Direct acting for reliable performance
- Resilient seating for tight shutoff
- Mountable in any position
