Specifications
- Valve Actuation
- Solenoid
- Body Material
- Brass
- Media
- Air, Inert Gas
- Pipe / Port Size
- 1/8 “
- Port Type
- NPTF
- Function
- 2 way – 2/2 Normally Closed
- Flow
- From 0.1 Cv to 0.5 Cv
- Voltage
- 24 AC; 110 AC; 115 AC; 120 AC; 208 AC; 220 AC; 230 AC; 440 AC; 480 AC; 6 DC; 24 DC; 12 DC; 48 DC; 120 DC; 240 DC – 50; 60
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Indoor
- Standards / Regulations
- CSA; Type 1; UL
Features
- Designed for individual installation or water-tight mounting in a panel enclosure
- Brass-body valves have threaded exhaust port for optional muffler installation, and screw or leaded terminals
- Plastic-body valves are designed for plastic or metallic tubing and have spade terminals
- Zero minimum pressure required
