Specifications
- Valve Actuation
- Solenoid, Solenoid – Direct Acting, Solenoid – Latching
- Body Material
- Brass, Brass – Nickel Plated, POM
- Media
- Air, Inert Gas, Water
- Pipe / Port Size
- M5
- Port Type
- Flange, Push-in
- Function
- 2 way – 2/2 Normally Closed, 2 way – 2/2 Normally Open, 3 way – 3/2 Universal, 3 way – 3/2 Normally Open, 3 way – 3/2 Normally Closed
- Flow
- Less than .05 Cv, From .05-.1 Cv, From 0.1 Cv to 0.5 Cv
- Voltage
- 6 DC, 12 DC, 24 DC
- Max Differential / Max Operating Pressure
- 0 to 232 PSI
- Operating Environment
- Indoor
- Standards / Regulations
- IP65, RoHS
Features
- Available in 2/2 NC/NO, 3/2 NC/NO and Universal versions, as well as proportional control and latching versions
- Low power versions (0.5W), and latching coil versions (power consumption close to zero) results in a decrease in OEM instrument power consumption as well as a decrease in heat transferred to the fluid media
- Small form-factor saves space in OEM instruments are well-suited for portable and hand-held field devices
- Multiple electrical connection options and a rotatable coil create greater flexibility in OEM instrument design and serviceability
- meets all relevant CE directives, and are RoHS compliant
