Specifications
- Valve Actuation
- Solenoid
- Body Material
- Aluminum
- Media
- Air, Inert Gas, Liquid Propane Gas, Natural Gas, Oxygen
- Pipe / Port Size
- ¾ “; 1 “; ¼ “; ½ “; 2 “; ½ “; 3 “
- Port Type
- NPTF
- Function
- 2 way – 2/2 Normally Closed, 2 way – 2/2 Normally Open
- Flow
- From 6.0 Cv to 14.0 Cv;Over 14.0 Cv, From 5.19 to 12 Kv;Over 12 kv
- Voltage
- 110 AC;115 AC;12 DC;120 AC;120 DC;208 AC;220 AC;230 AC;24 AC;24 DC;240 AC;240 DC;440 AC;48 DC;480 AC;6 DC | 50/60
- Max Differential / Max Operating Pressure
- Hazardous; Indoor; Outdoor
- Operating Environment
- Hazardous, Indoor, Outdoor
Features
- Low pressure drop and extremely high flow capacity make the valve ideal in low gas supply pressure applications and locations
- Visual indication of open and shut position meets NFPA and FM requirements for visual indication
- Proof of closure switch meets agency/code requirements for an electrical interlock of valve closed position
- 1/8-inch NPT pipe taps with plugs provide easier routine testing
- Broad ambient range of -40?F to 140?F is ideally suited for frigid and hot environments
- Optional NPT threaded flange adapters allow direct piping that simplifies installation and maintenance
- Silicon-free constructions are available for painting/finishing applications
- Most constructions available on ASCO SameDay or 5Day shipping program to keep production lines running smoothly
