Specifications
- Valve Actuation
- Solenoid
- Body Material
- Brass – Nickel Plated; Engineered Plastics; Stainless Steel
- Media
- Air, Inert Gas
- Pipe / Port Size
- 1/8 “; M5
- Port Type
- G ISO228/1-G BSPP
- Function
- 2 way – 2/2 Normally Closed
- Flow
- Less than .05 Cv; From .05-.1 Cv; From 0.1 Cv to 0.5 Cv
- Voltage
- 6 DC; 12 DC; 24 DC – 50/60
- Max Differential / Max Operating Pressure
- Vacuum to 150 PSIG
- Operating Environment
- Indoor
- Standards / Regulations
- IP65
Features
- Low hysteresis (< 5%), excellent repeatability (< 3%), and high sensitivity (< 2%) make the valves ideal for high-precision flow control
- Minimum operating pressure is not required, and the valves are well-suited for vacuum operation
- Compact frictionless architecture saves valuable space in analytical and medical instrumentation
- Power consumption as low as 1 W fulfills the most stringent instrument power requirements
- Meets all relevant CE directives, and is RoHS compliant for applications in lead-free environments
